ICON Vehicle Dynamics Stage 3 Suspension System Billet 2-Wheel Drive F-150 2015-2020

Uniquely tuned and valved to the lighter weight of your 2015-2020 2-wheel drive F-150, the rear shocks of the ICON Vehicle Dynamics Stage 3 Suspension System will transform your ride quality. Fitted with internal reservoirs for fresh cooling, this kit features shocks part of the 2.5 Aluminum series. They use one-piece aluminum cylinders, impact-extruded and hard-anodized for stellar strength and corrosion resistance. Coupled with the CAD-plated coilovers, they introduce your truck to boosted wheel travel without hampering towing capacity.

Features and Benefits:
- 2.5 Aluminum series rear shocks w/ internal reservoirs
- Shocks specially tuned & valved to 2015-2020 F-150
- One-piece, impact-extruded, hard anodized, aluminum cylinders
- Stellar damping & vehicle control on/off-road
- Boosts wheel travel, refines ride quality, & retains towing capacity
- Corrosion-resistant, CAD-plated, coilovers w/ 7/8” shaft
- Coilovers bear adjustable lift height of 0” to 3”
- Billet aluminum UCAs boost strength/alignment spec range
- UCAs feature heavy-duty, high-angle Delta Joint
- Delta Joint is zinc-plated & uses tough grease seal
- Components CNC-machined from 6061 aircraft-grade aluminum
- Lower bar pin built from high-strength, CNC-machined alloy
- FK rod end bearings boost longevity & minimize deflection
- Bolt-on installation w/o cutting/welding

Designed with 7/8” shafts, the kit’s coilovers offer users 0” to 3” in lift adjustability. To complement it, the included upper control arms made from billet aluminum bear an increased caster over stock. Not only does this let you run aggressive wheel and tire combos, but it also gives you the same alignment range as OEM to back it up. Plus, the heavy-duty and high-angle of the Delta Joint means you get articulation with little to no bind. With FK rod end bearings in place to minimize deflection, this bolt-on kit is a lasting way to refine damping performance and vehicle control no matter the terrain.

Vehicle Fitment:
- 2015-2020 Ford F-150
- For 2-wheel drive applications ONLY

Additional Notes:
- OEM wheels & tires fitment: not compatible with all available OE wheel/tire combinations. Aftermarket wheels with lower offset/less backspace are recommended.
- Recommended aftermarket wheels: 17x8.5" w/ 5” backspace / 6mm offset
- Recommended aftermarket wheels: 18x9" w/ 5.25" backspace / 6mm offset
- Recommended aftermarket wheels: 20x9" w/ 5.625" backspace / 16mm offset
- Recommended aftermarket tires: 33" x 11.50"
- Larger tires may fit but fender trimming and modifications will be required.
- Shocks are fully serviceable. Coilover heights indicated are for a stock-equipped vehicle.
- For models with a Power-Stroke diesel engine, the lift height range will be 0” to 2-1/2” over stock.
- Included rear shocks are compatible with 0” to 1" of rear lift over stock on most models.
