Vintage Air Gen 5 Magnum A/C Kit w/ SD-508 Compressor Ford F-100 289-351W 57-60 Small Block

This all-in-one A/C kit fits trucks powered by 289-351W small-block Ford engines, delivering powerful heating, air conditioning, and defrost. It is electronically controlled, eliminating outdated vacuum controls and cables for a more modern system. High-capacity heat exchangers, a variable-speed blower, and precision temperature management provide fast cabin comfort and dependable operation in any season. This complete kit includes the GEN 5 Magnum evaporator, SD-508 compressor, SuperFlow condenser, rotary control panel, vents, hose and fitting kit, compressor brackets, and installation hardware. Designed for use with R-134a refrigerant, it provides the major components needed to bring modern climate control to your 1957-1960 F-100!

Features and Benefits:
- Designed to fit 289-351w Small Block Ford Engines
- GEN 5 Magnum Evaporator kit included
- Multiple mounting options for an easier installation
- Rubber well-nut mounting points for improved NVH isolation
- Separate high-capacity A/C and heater coils with blend air door for rapid vent temperature adjustment
- OEM block-type expansion valve
- Injection molded case for optimal precision, strength and quality
- Injection molded blend air doors with integral rubber seals
- Removable access covers for coil service
- Interchangeable defrost and floor heat plenums for increased mounting flexibility
- Powder coated steel mounting brackets
- High performance variable speed blower assembly
- Large 2.5inch duct hose outlets for superior flow
- Adjustable A/C 3-knob control panel
- Switches can be removed individually to be mounted anywhere
- Control panel measures 5.25" by 1.25"
- Adjust temperature, fan speed and air flow direction
- Dual function pressure safety pressure switch
- Male thread binary safety switch
- Low and high-pressure protection 30psi-406psi
- Integrated O-ring for a leak free seal design
- Faster interior cooling time
- Includes installation mount brackets
- Measures in at 17-inches tall by 19-inches wide and .75-inch thick
- SuperFlow condenser comes with a black sleek finish
- Includes No. 8 fitting at the top and No. 6 fitting at the bottom
- Adjustable rectangle and ball style vent louvers
- Louvers feature a black and chrome finish
- Designed to be used with 2.5inch duct hoses
- Small block 289-351w engine compressor bracket

Kit Includes:
- SD-508 A/C Compressor (standard finish)
- GEN 5 Magnum Evaporator Kit
- Engine Compressor Bracket
- SuperFlow 17x19 Condenser with Brackets
- 14-piece Fitting Hose Kit with Drier and Bulkhead Fittings
- Male Binary Switch
- Gen IV-5 Rotary Control Panel Kit
- Under Dash Rectangle Louver Vent
- Under Dash Ball Louver Vent
- Instruction Guides

Please Note: Vintage Air systems are designed to operate with R134a refrigerant only. Use of any other refrigerant could damage your A/C system and/or vehicle, and possibly cause a fire, in addition to potentially voiding the warranties of the A/C system and its components.

Vehicle Fitment:
- 1957-1960 F-100
- Small Block Ford 289-351W Engine
