Ridetech Lower Control Arm for use with Shockwaves or Coilovers StrongArms Pair 1967-1970
- .219" Wall DOM Tubing
- Improves Handling
- Easy Installation
Pair of Ridetech StrongArm Lower Control Arms for use with Shockwaves or Coilovers on 1967, 1968, 1969 and 1970 Mustangs.
The Ridetech StrongArm is a precision engineered solution for Shockwave installation, ball joint binding and frame clearance issues that can haunt some vehicles. This set of tubular control arms was built with performance in mind. Development took place in Indiana on an actual running and driving vehicle so all fitment and performance issues could be properly addressed. Don't upgrade your suspension and reuse OEM stamped steel control arms. StrongArms are built with all of the care and experience you have come to expect from Ridetech.
StrongArms are jig welded with .219" wall DOM tubing for proper fit and long lasting strength and reliability. A 4-axis tube bender allows precise, repeatable bends. Optimized ball joint angle ensures no binding during extreme suspension travel. Working closely with Moog, Ridetech ensured the proper ball joints were selected for each application. StrongArms are designed with as few components as possible to keep things simple. A black powder coated finish creates lasting appearance and protection. StrongArms are preassembled with ball joints and bushings and ready to bolt on.
The lower StrongArm eliminates the strut rod with its one-piece design. Instead of rubber bushings used to attach the strut rod to the frame, Ridetech uses a bearing setup. The bearing setup gets rid of the compression that is experienced with hard braking and cornering. Lower arms use an eccentric eliminator. This plate has multiple positions to be used when aligning your Mustang. Once they are set, you don't have to worry about your alignment moving. Any fine tuning that is needed can be done with the upper control arm because it is fully adjustable.
Geometry of the suspension starts with the position of the frame mounts and height of the spindle. However, there are a few small aspects in control arm design that can make a big difference in how a vehicle drives and performs. Fore and aft positions of the ball joints are adjusted which creates extra caster potential. Ridetech makes sure the wheel is properly positioned in the wheel-well so 18" wheels fit like they should. Ball joint camber travel is re-centered to accommodate the new lowered ride height so the ball joint doesn't bind during extreme suspension movement. StrongArms are optimized to allow proper camber adjustment with a lowered ride height so a large stack of alignment shims is not needed.
Please Note: Lower control arms will not work with Kelsey Hayes style brake Calipers. The caliper contacts the lower control arm and decreases the turning radius.
*StrongArms must be used with Ridetech coilovers or Shockwaves.
California Residents: Proposition 65 Warning
Intermediate skill is required for this installation.
